| 評価される流れ: | 8.3a | 原産地: | 中国(本土) | 銘柄: | toptek | モデル番号: | TDG6000E | 評価される電圧: | 110,120,220,230,240,110/220,120/240 | 評価される力: | 5kw | 速度: | 3000/3600 rpm | 出力タイプ: | AC単一フェーズ | 頻度: | 50/60 ｈｚ | 色: | として顧客の要求 | ハンドルと車輪: | オプション | オルタネータ: | 100%銅巻線 | エンジン: | 4ストローク10hp出力 | 機能: | 磁気発生器 | oemサービス: | availavle | スタートシステム: | マニュアルと電気用オプション |
包装
| 包装: | 標準的な輸出カートン、 木製ケース任意のための700475x575ミリメートル20l/40 hq( セット): 102sets/216は、 nを設定し。 w/g。 w: 95/98kg |
(2kw~5kw)Diesel Powered Generators Prices for home use
1) using direct injection air-cooled diesel engine, long life, low fuel consumption;
2) special and various control panels are available for different market;
3) AVR automatic voltage to maintain stability and ensure a smooth power on the voltage fluctuation
sensitive equipment is especially important.
4) engine oil warming system, fuel display stables, etc;
5) standby power for home use, leisure, agriculture and commerce.
Specification of powered generators :
| Model | TDG2500(E) | ||
| Generator | Frequency(Hz) | 50Hz | 60Hz |
| Max. AC output(KW) | 2.5kva | 2.75kva | |
| Rated AC output(KW) | 2.25kva | 2.5kva | |
| DC.Current(A) | 12V/8.3A | ||
| Phase. | Single phase | ||
| Insulation. | F | ||
| Power factor(cosφ) | 1 | ||
| Rated AC voltage(V) | 110,120,220,230,240,110/220,120/240 | ||
| Engine | Model. | TD170F | |
| Engine Type. | Air Cooled,4 Stroke,Single Cylinder,Vertical | ||
| Max power output(HP) | 4.2HP | ||
| Displacement(cc) | 219cc | ||
| Compressing ratio. | 20:1 | ||
| Engine speed(rpm) | 3000rpm | 3600rpm | |
| Starting system. | Recoil or Electric. | ||
| Lubracation System | Pressure splashed | ||
| Fuel tank capacity(L) | 12.5L | ||
| Lube oil capacity (L) | 0.75L | ||
| Noise level(dB / 7M) | 80dB(A) | ||
| conveyance | N.W./G.W.(kg) | 65/ 68kg | |
| Packing Dimension(mm) | 660475x550 mm | ||
| 20'L/40'HQ (set) | 156sets/336sets | ||
Packing detals: Standard export carton or as customer's request
Shipping port: SHANGHAI port
TOPTEK provides a full line of brand new and high quality products, each and every units are strictly factory tested before shipment,all the generators from TOPTEK are CE approved,factory are already passed the ISO9001:2008 quality managment system certification,relying on excellent product quality, thoughtful service, good reputation, creating a brilliant performance.
we only to produce diesel engine, diesel generator, diesel water pump and diesel tiller, because the focus, we are more professional.
In addition, we have a variety of factories working close with us and we are able to provide excellent price and
quality for our customers, also the other similar products as customers' requirement.
Factory profile
FAQ for powered generators :
1) We are ISO certified factory, all the price base on factory direct
2) Our main sales market: Philippines, Pakistan, Middle East countries such as Yemen, Saudi Arabia, Egypt, etc.
3) Shipment port: Shanghai/ Fuzhou/ Wenzhou
4) MOQ: 10sets
5) Delivey time: 20~25 working days after receiving deposit
6) For optional configuration: electric start with battery, LCD panel, ATS, wheels and handles
7) Payment terms: T/T 30% as deposit, the balance paid before shipment or against electronic B/L or L/C.
8) Packing: standard export carton case package, wooden case for optional
9) Spare parts: it is available for container order, 2% of goods' value
10) Quality warranty is according to our standard conditions
Service and parts are available from TOPTEK.All the products from TOPTEK are CE and ISO9001:2008 marked.
During the Warranty:
If quality & assembling problem caused troubles, we take responsible on spare parts and all service fees. If misuse or human factors caused the trouble, users shall take responsible on spare parts and all service fees.
any more questions pls contact person: Arthur Zhang
