| 電圧: | 380ボルト/ 220ボルト | 原産地: | 中国(本土) | 銘柄: | db | モデル番号: | MQ320A | 重量: | 2100KGS | 自動等級: | 自動 | 力(W): | 5kw | タイプ: | ラベルダイ切断機 | 保証: | 1年 | 条件: | 新しい | 認証: | ce、iso9001 | 次元(L*W*H): | 2600 × 1100 × 1400 | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | ダイ切断タイプ: | フラットにフラット | ホットスタンピングユニット: | オプション | 積層ユニット: | はい | ロールにシート切断: | はい | メインモータ: | 安川サーボモータ | インバータブランド: | パナソニック | ダイ切断幅: | 320ミリメートル | ダイ切断速度: | 180 t/min | のgurantee年: | 1年 |
包装
| 包装: | 標準エクスポート木製ケース |
DB-MQ320 Automatic Sticker/Adhesive Label Die Cutting Machine
Application
Our DB-MQ320 AUTOMATIC STICKER/ADHESIVE LABEL DIE CUTTING MACHINE
is widly used for die cut self adhesive labels, dacron film labels, laser anti-false labels, diversified electronic labels etc .
Suitable Material
Sticker productions: diversified electronic, electrical appliance, mobile phone special rubber cushions, silicone rubber cushions, magic tape, electric conductive tape, powerful double side adhesive, suneast, 3M,Sony special binding products. Tapes for backlight screen, electronic industry, IT film switch and car making industry.
Dustproof materials: cosmetic cotton, camera cotton, high-density sponge, filtering sponge, dust net and on-woven fabric.
Shock absorbing products: EVA tape, rubber, transparent cushion, PORON cushion, 3M, inflammable retardant EVA, high foam.
Insulation, EMI: fireproof paper, aluminum foil, copper foil, PVC, PET, brown paper, sponge sheath, pearl cotton sheath.
Heat insulation materials: silicone sheet, transparent mica, fiber cloth, heat insulation cotton (fabric).
Characteristics:
1. It’s a high precision flat bed die cutter
2. Material feeding & cutting are controlled by YASKAWA servo motor
3. Two sides of printed label & longitudinal direction are positioned by three photo-electrical eyes
4. Cutting, waste wind up, sheeting or rewinding can be completed in one pass
5. Automatic paper feeding-double photo-electrical deviation control-color mark.
dried.
Standard Configuration for 6-color flexogrphic printing machine:
1.One die cutting stations;
2. One unwinder;
3.One sheeter;
4. Lamination station,
5.Touch screen, Inverter;
6.PLC, Servo Motor; Electric eyes
Main Specification
Common Specification | Raw material | Sticky productions,Dustprof materials, Shock absorbing products,Insulation, EMI,Heat insulation materials.etc | |||
Model type | DBMQ-320A | DBMQ-420A | DBMQ-620A | ||
Raw material width | 350mm | 450mm | 650mm | ||
Max.unwinding diameter | 450mm | 500mm | 500mm | ||
Max.die-cutting width | 320mm | 420mm | 620mm | ||
Die-cutting length | 290mm | 400mm | 600mm | ||
Die-cutting speed | 20-180 t/min | 20-150 t/min | 20-100 t/min | ||
Total power | 3KW | 4.5kw | 6.5kw | ||
Power voltage | 380V/220V±10% | 380V/220V±10% | 380V/220V±10% | ||
Weight of machine | 2100KG | 2300KG | 2800KG | ||
Overal dimension ( L X W X H ) mm | 2600950x1400 | 26001100x1400 | 27001350x1400 | ||
Tension control range | 3-5KG/Full widht | ||||
Control motor | Servo Motor (YASKAWA) | ||||
Machine color | MUNCELL NO. F-299002 (User Advice) | ||||
OP Panel color | MUNCELL NO. F-553507 (User Advice) | ||||
WINDER | Unwinding & rewinding part | Air shaft | |||
Material outer Dia | Φ450/Φ500 | ||||
Air-Shaft fixing type | 3" Shaft + Adapter(AL or MC nylon) (User Advice) | ||||
1.DB-MQ320 AUTOMATIC STICKER/ADHESIVE LABEL DIE CUTTING MACHINE
6
.OUR SERVICE FOR DB-MQ320 AUTOMATIC STICKER/ADHESIVE LABEL DIE CUTTING MACHINE
1. Purchase Service
DABA COMPANY have a specialize and efficiency working team.If you are new on the printing and packing area ,Some samples of your products could be shew to us will be appreicate ,we will give you specialized suggestion of whole work .
2. Shipping Service
DABA COMPANY have a spcialized and independent department which just for shipping the buyer's goods .The workers are knowing T/T,L/C Items well.all Exported documents could be made perfectly .
DABA COMPNAY copperate with the most famous shipping company in China also.They could provide the best and economic shipping ways to the buyer's port.
3.Installation Services
Installation Services are available with all DABA Company machines.DABA Comapny will dispatch technician to The Buyer's factory to installation and preoperation of machines .But the buyer need to surpply the round trip tickets ,food ,hotel cost.
4.Clients Training Services
DABA Company advise The buyer could send own technican come to DABA factory to learn how to operate machines.DABA Company technician will teach and train the lerners hand by hand till he can operate machine by himself.
Obviouslly, Traning within Installation period is acceptable.
5.After Sales Service
DABA Company machines guarantee time is one year.
Many easy broken spare parts will be prepared in the tool box together with machines.
Any parts broken ,Just a pictures or a videos.
The new free parts will reach within 3-7 Express working days .
